Concealed Ceiling Installation
Direct interface with architectural FCU return air diffusers and grilles.
The CAM Series is an ultra-thin (80 mm) concealed plasma micro-electrostatic air disinfection and particulate elimination device matched specifically to Fan Coil Unit (FCU) return air grilles. It continuously purifies circulating indoor air by capturing particles down to 0.01 μm and neutralizing airborne bacteria and viruses with zero consumable filter waste.
Architectural Design Friendly:
Dimensions correspond directly to standard commercial FCU coil sizes. The 80 mm profile easily satisfies shallow false-ceiling depths, while return grilles can be customized to match any architectural interior decor.
| Standard Product Dimensions (W × L × H mm) | Matched Air Conditioning Airflow (m³/h) | Matched Standard FCU Size | Nominal Pressure Resistance |
|---|---|---|---|
| 226 × 450 × 80 mm | 340 m³/h | FCU 200 CFM Class | ≤ 18 Pa |
| 226 × 610 × 80 mm | 510 m³/h | FCU 300 CFM Class | ≤ 18 Pa |
| 226 × 770 × 80 mm | 680 m³/h | FCU 400 CFM Class | ≤ 20 Pa |
| 226 × 945 × 80 mm | 850 m³/h | FCU 500 CFM Class | ≤ 20 Pa |
| 226 × 1135 × 80 mm | 1,020 m³/h | FCU 600 CFM Class | ≤ 22 Pa |
| 226 × 1455 × 80 mm | 1,360 m³/h | FCU 800 CFM Class | ≤ 22 Pa |
| 226 × 1805 × 80 mm | 1,700 m³/h | FCU 1000 CFM Class | ≤ 24 Pa |
